D/N function - IR cut filter



Bullet AHD Multistandard Camera

NVAHD-2DN5106MH/IR-1

Key features
  • D/N function - IR cut filter
  • resolution 1080p
  • Lens: varifocal, f=2.8 ~ 12 mm/F1.4
  • multistandard: AHD, CVI, TVI, 960H
  • Min. Illumination from 0.0001 lx (0 lx, IR on)
  • IR LED, range up to 35 m
Functions
Image Sensor

CMOS sensor 1/2.9” SONY

Operating mode

AHD 1080p, TVI 1080p, CVI 1080p, analog 960H

Number of Effective Pixels

1920 (H) x 1080 (V)

Resolution

1080p

Min. Illumination

0.1 lx/F1.4 - color mode,

0.05 lx/F1.4 - B/W mode,

0.005 lx/F1.4 - color mode (DSS),

0.0001 lx/F1.4 - B/W mode (DSS),

0 lx (IR on) - B/W mode

S/N Ratio

> 52 dB (AGC off)

Electronic Shutter

auto/manual: 1/25 s ~ 1/50000 s

Digital Slow Shutter (DSS)

up to 30x

High Light Compensation (HLC)

yes

Wide Dynamic Range (WDR)

yes

Digital Noise Reduction (DNR)

2D, 3D

Defog Function (F-DNR)

yes

Lens
Lens Type

varifocal, f=2.8 ~ 12 mm/F1.4

Day/Night
Switching Type

mechanical IR cut filter

Switching Mode

auto, manual

Switching Level Adjustment

yes

Switching Delay

0 ~ 60 s

Visible Light Sensor

yes

Other functions
OSD

languages: Polish, English, Russian, others (joystick on the cable)

Privacy Zones

4

Motion Detection

yes

Image Processing

180˚ image rotation, sharpening, mirror effect

Remote control

Yes (COAX protocol)

IR LED
LED Number

30

Range

35 m

Angle

120°

Interfaces
Video Output

BNC, 1.0 Vp-p, 75 Ohm

Installation parameters
Dimensions (mm)

with bracket: 84 (Ф) x 270 (L)

Weight

0.7 kg

Degree of Protection

IP 66 (details in the user’s manual)

Enclosure

aluminium, white, fully cable managed wall mount bracket in-set included

Power Supply

12 VDC

Power Consumption

1.2 W,

5 W (IR on)

Operating Temperature

-30°C ~ 40°C

* Note: UTC functionality available on cameras with serial numbers starting from: 150611xxxx
Remote controller type: NV-RCUTC-35HD
File name Description
NVAHD-2DN5106MH-IR-1_EN_PL_v1.0.pdf
User manual
4.13 MB
CE NVAHD 2DN5101_2_6_5202MHIR1P_EN.pdf
Certificate
91.57 KB
