Speed Dome AHD Camera NVAHD-2DN5220MSD/IRH-2

Image Sensor	CMOS sensor 1/2.8” SONY
Operating mode	AHD 1080p, TVI 1080p, CVI 1080p, analog 960H
Number of Effective Pixels	1920 (H) x 1080 (V)
Resolution	1080p
Min. Illumination	0.0002 lx/F1.7 - color mode, 0 lx (IR on) - B/W mode
S/N Ratio	> 52 dB (AGC off)
Electronic Shutter	auto/manual: 1/25 s ~ 1/50000 s
Digital Slow Shutter (DSS)	up to 30x
High Light Compensation (HLC)	yes
Wide Dynamic Range (WDR)	yes
Digital Noise Reduction (DNR)	2D, 3D
Defog Function (F-DNR)	yes
Lens
Optical Zoom	20x
Lens Type	motorized, f=4.7 ~ 94 mm/F1.7
Auto-focus	continuous, zoom trigger, day/night mode trigger
Day/Night
Switching Type	mechanical IR cut filter
Switching Mode	auto, manual, time
Switching Level Adjustment	yes
Switching Delay	0 ~ 60 s
Visible Light Sensor	yes
PTZ
Preset Commands	88
Tours	4 (up to 12 presets per tour)
Auto-Scans	4
Patterns	4
Tilt/Pan Range	0° ~ 97°/360° (continuous)
Pan/Tilt Speed	up to 200°/s (proportional to zoom)
Protocols	Pelco-D, Pelco-P, COAX
Other functions
OSD	languages: English
Access Password	number of characters: 4 numbers
Real-time Clock	yes
Image Processing	180˚ image rotation, sharpening, mirror effect, negative, picture-freeze, vertical flip
IR LED
LED Number	12
Range	up to 150 m (depends on current optical zoom value)
Angle	up to 60° (depends on current optical zoom value)
Smart IR	yes (software support)
Interfaces
Video Output	BNC, 1.0 Vp-p, 75 Ohm
Alarm Input/Output	4 (NO/NC)/1 relay type
RS-485	yes
Installation parameters
Dimensions (mm)	226 (Ф) x 337 (H) with bracket: 226 (W) x 430 (H) x 345 (L)
Weight	5 kg with bracket: 6 kg
Degree of Protection	IP 66 (details in the user’s manual)
Enclosure	aluminium, white, in set: outdoor housing (integrated with the camera), wall mount bracket
Power Supply	24 VDC (100 ~ 240 VAC/24 VDC PSU in-set included)
Power Consumption	6 W, 30 W (IR illuminator on), 50 W (IR and heater on)
Operating Temperature	-40°C ~ 60°C
Humidity	max. 85%, relative (non-condensing)
Built-in Heater/Fan	yes/no


Image Sensor

CMOS sensor 1/2.8” SONY

Operating mode

AHD 1080p, TVI 1080p, CVI 1080p, analog 960H

Number of Effective Pixels

1920 (H) x 1080 (V)

Resolution

1080p

Min. Illumination

0.0002 lx/F1.7 - color mode,

0 lx (IR on) - B/W mode

S/N Ratio

> 52 dB (AGC off)

Electronic Shutter

auto/manual: 1/25 s ~ 1/50000 s

Digital Slow Shutter (DSS)

up to 30x

High Light Compensation (HLC)

yes

Wide Dynamic Range (WDR)

yes

Digital Noise Reduction (DNR)

2D, 3D

Defog Function (F-DNR)

yes

Lens

Optical Zoom

20x

Lens Type

motorized, f=4.7 ~ 94 mm/F1.7

Auto-focus

continuous, zoom trigger, day/night mode trigger

Day/Night

Switching Type

mechanical IR cut filter

Switching Mode

auto, manual, time

Switching Level Adjustment

yes

Switching Delay

0 ~ 60 s

Visible Light Sensor

yes

PTZ

Preset Commands

Tours

4 (up to 12 presets per tour)

Auto-Scans

Patterns

Tilt/Pan Range

0° ~ 97°/360° (continuous)

Pan/Tilt Speed

up to 200°/s (proportional to zoom)

Protocols

Pelco-D, Pelco-P, COAX

Other functions

OSD

languages: English

Access Password

number of characters: 4 numbers

Real-time Clock

yes

Image Processing

180˚ image rotation, sharpening, mirror effect, negative, picture-freeze, vertical flip

IR LED

LED Number

Range

up to 150 m (depends on current optical zoom value)

Angle

up to 60° (depends on current optical zoom value)

Smart IR

yes (software support)

Interfaces

Video Output

BNC, 1.0 Vp-p, 75 Ohm

Alarm Input/Output

4 (NO/NC)/1 relay type

RS-485

yes

Installation parameters

Dimensions (mm)

226 (Ф) x 337 (H) with bracket: 226 (W) x 430 (H) x 345 (L)

Weight

5 kg with bracket: 6 kg

Degree of Protection

IP 66 (details in the user’s manual)

Enclosure

aluminium, white, in set: outdoor housing (integrated with the camera), wall mount bracket

Power Supply

24 VDC (100 ~ 240 VAC/24 VDC PSU in-set included)

Power Consumption

6 W,

30 W (IR illuminator on),

50 W (IR and heater on)

Operating Temperature

-40°C ~ 60°C

Humidity

max. 85%, relative (non-condensing)

Built-in Heater/Fan

yes/no
